Presonus Quantum 2626

Timeless audio

Every design decision during Quantum 2626 audio interface’s engineering was made with one goal in mind: blazing-fast speed without any sonic compromise. The Quantum-series proprietary Thunderbolt driver was written from the ground up to deliver ultra-low-latency performance while maximizing efficiency. Cutting-edge 24-bit, 192 kHz converters with 115 dB of dynamic range and superior low-jitter clocking—coupled with our ultra-transparent, pure analog XMAX preamps—result in superb audio quality with the lowest round-trip latency of any audio interface available (< 1 ms*).

General Features

• 26x26 Thunderbolt 3 ultra-low-latency audio interface
• <1 ms roundtrip latency*; record direct to DAW with your favorite plug-ins engaged
• 24-Bit/192kHz Operation with high-quality 115 dB A/D/A converters
• Studio One Artist and Studio Magic plug-in bundle included

Flexible Connectivity

• Simultaneous I/O up to 26 inputs / 26 outputs (at 44.1 or 48 kHz)
• 8 pristine XMAX preamps
• 2 Instrument Inputs
• 8 balanced line inputs
• Dual headphone outputs with independent level control
• Balanced stereo main outputs with independent level control
• 8 DC Coupled balanced line outputs
• 2 preamp direct outputs with returns to insert outboard gear
• Main Output Level Control
• Balanced Stereo Main Output (TRS)
• Eight Balanced Line Outputs (TRS (outs 1 & 2 share a DAC with the main output))
• Two Preamp Outputs (channels 1 & 2)
• Two Line Returns (channels 1 & 2)
• ADAT Optical/Dual SMUX inputs/outputs: 16x16 channels at 44.1 or 48 kHz; 8x8 channels at 88.2 or 96 kHz
• Stereo S/PDIF coaxial input and output

Digitalia

• Thunderbolt 3 high-speed bus
• 24-bit resolution and up to 192 kHz sampling rate
• BNC word clock input and output with low-jitter clocking
• MIDI I/O

Physical

• Road-rugged construction with all-metal chassis and metal knobs
• 1U rack-mountable
• 12 VDC external power supply (included)
